Remote control commands
R&S
®
RTP
1918User Manual 1337.9952.02 ─ 12
Suffix:
<m>
.
*
Query parameters:
<SearchName>
Return values:
<Data>
Usage: Query only
SEARch:RESult:MPHY:FRAMe<m>:FTYPe? <SearchName>
Returns the type of frame for the selected frame within the search result.
Suffix:
<m>
.
*
Query parameters:
<SearchName>
Return values:
<FrameType> BURST | ADAPT | LCC | DLPDUSOF | DLPDUCOF |
DLPDUEOF | DLPDUNAC | DLPDUAFC | PACP | TRIGUPR0 |
TRIGUPR1 | TRIGUPR2 | SKIP | FILLER | SPACER |
UNKNOWN
BURST
M-PHY burst frame.
ADAPT
M-PHY Adapt frame. This control frame is used for clock/bit syn-
chronization.
LCC
M-PHY LCC frame. This control frame is used for line configura-
tion depending on the LCC Type.
DLPDUSOF | DLPDUCOF | DLPDUEOF | DLPDUNAC |
DLPDUAFC
UniPro DL PDU frame.
PACP
UniPro frame. This control frame is used mainly for power mode
change and L1.5 link management.
TRIGUPR0 | TRIGUPR1 | TRIGUPR2
UniPro frame. This control frame is used for link startup
sequence.
SKIP
UniPro frame with Skip symbols for reducing protocol payload
bandwidth.
FILLER
M-PHY or UniPro frame with filler words to maintain transmis-
sion activity.
