Remote control commands
R&S
®
RTP
2282User Manual 1337.9952.02 ─ 12
Parameters:
<State> ON | OFF
*RST: ON
ADVJitter<m>:RESult:VERTical:NSContinuous <State>
If enabled, the measurement scale for the noise spectrum is set automatically.
If disabled you can manually set a ADVJitter<m>:RESult:COMPonents<n>:
SCALe and a ADVJitter<m>:RESult:COMPonents<n>:OFFSet.
Suffix:
<m>
.
1..2
Parameters:
<State> ON | OFF
*RST: ON
ADVJitter<m>:RESult:COMPonents<n>:SCALe <Scale>
Sets the scale for the selected component.
You can set separate scale values for:
●
n=1 (symbol rate)
●
n= 2 (symbol duration)
●
n= 4...16: sets only one offset value that is relevant for all advanced jitter com-
ponents.
●
n= 17...29: sets only one offset value that is relevant for all advanced noise
components.
Suffix:
<m>
.
1..2
<n> 1..29
See Table 22-20
Parameters:
<Scale> Range: 1E-15 to 1E+15
Increment: 10E-6
*RST: 0.5
Default unit: s/div
ADVJitter<m>:RESult:COMPonents<n>:OFFSet <Offset>
Sets the offset for the selected component.
You can set separate offset values for:
●
n=1 (symbol rate)
●
n= 2 (symbol duration)
Jitter analysis and clock data recovery
