Parameters:
<IdentifierType> B11 | B29 | ANY
ANY
The ID type and ID pattern are not relevant for the trigger condi-
tion.
If the trigger type is "Identifier", the instrument triggers on any
identifier in the specified frame type.
If the trigger type is "Identifier + Data", set the "ID type" to "Any"
if you want to trigger only on data.
*RST: ANY
TRIGger:CAN:TYPE
<TriggerType>
Depending on the selected CAN trigger type, different additional parameters are avail-
able.
Parameters:
<TriggerType> STOF | EOF | FTYP | ID | IDDT | ERRC
STOF
Triggers on the stop bit of the sync field.
EOF
Triggers after a wakeup frame.
FTYP
Triggers on a specified frame type (data, remote, error, or over-
load). For data and remote frames, also the identifier format is
considered.
ID
Sets the trigger to a specific identifier or an identifier range. Only
the 6-bit identifier without parity bits is considered, not the pro-
tected identifier.
IDDT
Sets the trigger to a combination of identifier and data condition.
The instrument triggers at the end of the last byte of the speci-
fied data pattern.
ERRC
Identifies various errors in the frame. You can select one or
more error types as the trigger condition.
*RST:
STOF
TRIGger:CAN:FDATa:BRS <BRSBit>
Sets the bit rate switch bit.
Parameters:
<BRSBit> ZERO | ONE | DC
*RST: DC
