Remote Control Commands
R&S
®
Scope Rider RTH
458User Manual 1326.1578.02 ─ 12
TRIGger:CAN:FDATa:DPOSition <ByteOffset>
Sets the byte offset, that defines the start position of the data for the data pattern com-
parison.
The setting is available in CAN FD option R&S RTH-K9.
Parameters:
<ByteOffset> Range: 0 to 63
Increment: 1
*RST: 0
TRIGger:CAN:FDATa:ESI <ESIBit>
Sets the error state indicator bit.
Parameters:
<ESIBit> ZERO | ONE | DC
DC: do not care, bit is nor relevant.
*RST: DC
TRIGger:CAN:FDATa:FDF <FDFBit>
Specifies the CAN FD frame format. It corresponds to the EDL bit (extended data
length), which only exists in CAN FD format.
Parameters:
<FDFBit> ZERO | ONE | DC
ONE: CAN FD
ZERO: CAN.
DC: do not care, the format is not relevant.
*RST: DC
TRIGger:CAN:FDATa:SCERror <StuffCountError>
Triggers on stuff count errors. A stuff count error occurs if the received stuff count value
does not match the value calculated from the own stuff bit count.
Only relevant for CAN FD signals in ISO standard (BUS:CAN:FDATa:PSTandard is
set to ISO).
Parameters:
<StuffCountError> ON | OFF
*RST: ON
15.11.5.3 CAN Decode Results
The frame suffix <m> selects the frame index for which the result is queried.
Protocol Analysis
