195
* When Tx/Rx Edit SW ([MIDI]) is ON and Tx/Rx Edit Mode ([MIDI]) is set to MODE2,
the Tx/Rx Setting ([MIDI]) will be valid. In this case, this message will change the
value of the parameter assigned to the received control change for the part specified by
PANEL SELECT. Also, a control change will be transmitted from MIDI OUT on the
Part MIDI CH ([PART]) of that part.
* Tx/Rx settings ([MIDI]) can be made for controller numbers 1 to 31 and 33 to 95. Refer
to Transmit/Receive Setting List (p.188) for the default settings.
❍ Bank Select (Controller number 0, 32)
status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
mm,ll=Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)
* Regardless of the Tx/Rx ProgChg SW ([MIDI]) setting, this is received when Remote
KBD CH ([MIDI]) is ALL or when the MIDI channel of the bank select message match-
es.
* If [PERFORM/PATCH SELECT] is off (PERFORM) when this message is received, the
performance bank will be specified. If [PERFORM/PATCH SELECT] is on (PATCH),
the bank of the patch for the part selected by PANEL SELECT will be specified.
* Bank Select processing will be suspended until a Program Change message is received.
* If an unavailable (nonexistent) Bank Select number is received it will be ignored, and
only the Program Change will be received.
* The Patches corresponding to each Bank Select are as follows.
-------------+--------------+--------------------------
Bank Select | Program No. | Group Patch No.
MSB | LSB | |
------+------+--------------+--------------------------
50H | 00H | 00H - 3FH | User A 11 - 88
| 00H | 40H - 7FH | User B 11 - 88
------+------+--------------+--------------------------
51H | 00H | 00H - 3FH | Preset 1 A 11 - 88
| 00H | 40H - 7FH | Preset 1 B 11 - 88
| 01H | 00H - 3FH | Preset 2 A 11 - 88
| 01H | 40H - 7FH | Preset 2 B 11 - 88
| 02H | 00H - 3FH | Preset 3 A 11 - 88
| 02H | 40H - 7FH | Preset 3 B 11 - 88
------+------+--------------+--------------------------
52H | 00H | 00H - 3FH | Card 01 A 11 - 88
| 00H | 40H - 7FH | Card 01 B 11 - 88
| 01H | 00H - 3FH | Card 02 A 11 - 88
| 01H | 40H - 7FH | Card 02 B 11 - 88
| : | : | : :
| 1FH | 00H - 3FH | Card 32 A 11 - 88
| 1FH | 40H - 7FH | Card 32 B 11 - 88
+------+--------------+--------------------------
|*)20H | 00H - 3FH | Card 33 A 11 - 88
| 20H | 40H - 7FH | Card 33 B 11 - 88
| 21H | 00H - 3FH | Card 34 A 11 - 88
| 21H | 40H - 7FH | Card 34 B 11 - 88
| : | : | : :
| 3FH | 00H - 3FH | Card 64 A 11 - 88
| 3FH | 40H - 7FH | Card 64 B 11 - 88
------+------+--------------+--------------------------
*) Bank Select LSB 20H - 3FH can be used only with the S4M-5.
* The Performances corresponding to each Bank Select are as follows.
-------------+--------------+--------------------------
Bank Select | Program No. | Group Perform No.
MSB | LSB | |
------+------+--------------+--------------------------
50H | 00H | 00H - 3FH | User 11 - 88
------+------+--------------+--------------------------
51H | 00H | 00H - 3FH | Preset 1 11 - 88
| 01H | 00H - 3FH | Preset 2 11 - 88
| 02H | 00H - 3FH | Preset 3 11 - 88
------+------+--------------+--------------------------
52H | 00H | 00H - 3FH | Card 01 11 - 88
| 01H | 00H - 3FH | Card 02 11 - 88
| 02H | 00H - 3FH | Card 03 11 - 88
| : | : | : :
| 1FH | 00H - 3FH | Card 32 11 - 88
+------+--------------+--------------------------
|*)20H | 00H - 3FH | Card 33 11 - 88
| : | : | : :
| 3FH | 00H - 3FH | Card 64 11 - 88
------+------+--------------+--------------------------
*) Bank Select LSB 20H - 3FH can be used only with the S4M-5.
❍ Modulation (Controller number 1)
status
2nd byte 3rd byte
BnH 01H vvH
* This will control the pitch, cutoff, or amplitude modulation depth for the respective
PITCH/FILTER/AMP[DEPTH] parameter of MODULATION(LFO2).
* This is not reset to the default value when a patch program change is received.
* This will be reset to the default value when a performance program change is received.
❍ Breath type (Controller number 2)
status 2nd byte 3rd byte
BnH 02H vvH
❍ Foot type (Controller number 4)
status 2nd byte 3rd byte
BnH 04H vvH
❍ Portamento Time (Controller number 5)
status 2nd byte 3rd byte
BnH 05H vvH
* This will modify the PORTAMENTO [TIME] value.
❍ Data Entry (Controller number 6, 38)
status 2nd byte 3rd byte
BnH 06H mmH
BnH 26H llH
❍ Volume (Controller number 7)
status 2nd byte 3rd byte
BnH 07H vvH
❍ Balance (Controller number 8)
status 2nd byte 3rd byte
BnH 08H vvH
❍ Panpot (Controller number 10)
status 2nd byte
3rd byte
BnH 0AH vvH
❍ Expression (Controller number 11)
status
2nd byte 3rd byte
BnH 0BH vvH
* This adjusts the volume of the part. Expression messages are used to create variation in
dynamics (expression pedal, crescendo, decrescendo etc.) while you play.
* This is not reset to the default value when a patch program change is received.
* This is reset to the default value when a performance program change is received.
❍ Effect Control1 (Controller number 12)
status 2nd byte 3rd byte
BnH 0CH vvH
❍ Effect Control2 (Controller number 13)
status 2nd byte 3rd byte
BnH 0DH vvH
❍ General Purpose Controller1–4 (Controller number 16–19)
status 2nd byte
3rd byte
BnH 10-13H vvH
❍ Hold1 (Controller number 64)
status 2nd byte
3rd byte
BnH 40H xxH
* This will hold notes which are currently in a note-on state.
❍ Portamento (Controller number 65)
status 2nd byte 3rd byte
BnH 41H xxH
* This switches PORTAMENTO [ON] on/off.
❍ Sound Controller1–10 (Controller number 70–79)
status 2nd byte 3rd byte
BnH 46-4FH vvH
❍ General Purpose Controllers 5–8 (Controller number 80–83)
status 2nd byte 3rd byte
BnH 50-53H vvH
