Roland JX-10 - MIDI Channel and Key Mode Relation; Using JX-10 as a Single MIDI Sound Module

Manual Version 3.21
Page. 61 of 73
5. Relation between MIDI CH (transmitting) and Key Mode
[17 KEY MODE]
MIDI CH which sends Key messages
[67 MIDI KEY MODE]
MIDI CH which sends Note On/Off messages
DUAL
T-VOICE
X-FADE
SPLIT
UP WHOLE
LO WHOLE
Only the Upper MIDI CH.
Only the Upper MIDI CH.
Only the Upper MIDI CH.
The Upper MIDI CH and the Lower MIDI CH at
the set split point.
Only the Upper MIDI CH.
Only the Upper MIDI CH.
SPLIT
UPPER
LOWER
LAYER
The Upper MIDI CH and the Lower MIDI CH that
will vary depending on the setting of Factor 68,
"MIDI SPLIT POINT".
Only the Upper MIDI CH.
Only the Lower MIDI CH.
Both the Upper MIDI CH and the Lower MIDI
CH’s send the same Key messages
simultaneously.
Note:
When the Patch Memory Factor 67 “MIDI KEY MODE”
is set to OFF, MIDI CH which sends Key messages is
selected with Factor 17 “KEY MODE”.
Note:
Factor 67, “MIDI KEY MODE”
; SPLIT, UPPER,
LOWER or
LAYER determines the MIDI CH which
sends Key messages regardl
ess of the Key Mode of
the JX-10.
6. Using the JX-10 as one MIDI Sound Module
a) To use the JX-10 as one MIDI Sound Module
• MIDI Setting on the MIDI Keyboard
MIDI CHANNEL ........................................ 1
PROGRAM CHANGE ............................... ON
• Set the MIDI functions on the JX-10 as follows
[16 PATCH MEMORY ................................. 1]
[13 UPPER MIDI CH ................................... 1]
[31 UP PROGRAM CHANGE................. OFF]
[14 LOWER MIDI CH .................................. 1]
[41 LO PROGRAM CHANGE................. OFF]
In this setting, Patch Memories of the JX-10 are changed by the Program Change messages transmitted from the
external MIDI Keyboard.
Program Change number which is
transmitted to the JX-10’s MIDI IN
Patch Memory of the JX-10
which will change
1
64
65
128
INTERNAL
INTERNAL
CARTRIDGE
CARTRIDGE
A – 1
H – 8
A – 1
H – 8
Unless a Memory Cartridge (M-64C) which contains Patch Memories for the JX-10 is connected to the JX-10,
Patch Memories which correspond to Program Change Numbers from 65 to 128 will not change.
MIDI
Keyboard
JX-10
MIDI OUT
MIDI IN
