Appendix
Appendix
M-200i: LIVE MIXING CONSOLE
Mixing Channels
INPUT : 32 channels
BUS : MAIN L/R, 8 AUX buses, 4 MATRIX buses
OUTPUT: 14 ports (Max 54 ports When using REAC Devices )
Signal Processing
AD/DA Conversion: 24 bit
Sample Rate: 48.0 kHz or 44.1 kHz
Frequency Response
ASSIGNABLE OUTPUT jacks (1 to 10): -2 dB / +0 dB (20k ohms load, +4 dBu, typ.)
MAIN OUTPUT jacks (L, R): -2 dB / +0 dB (20k ohms load, +4 dBu, typ.)
PHONES jack: -3 dB / +0 dB (40 ohms load, 150 mW, typ.)
* Sample Rate: 48.0 kHz or 44.1 kHz
* Input Connector: INPUT 1 to 24 (Pad: ON, Input sens: +4 dBu, 20 Hz to 20 kHz)
Total Harmonic Distortion + Noise
ASSIGNABLE OUTPUT jacks (1 to 10): 0.05 % (+4 dBu, typ.)
MAIN OUTPUT jacks (L, R): 0.05 % (+4 dBu, typ.)
PHONES jack: 0.05 % (40 ohms load, 150 mW, typ.)
* Sample Rate: 48.0 kHz or 44.1 kHz
* Input Connector: INPUT 1 to 24 (Input sens: +4 dBu, 20 Hz to 20 kHz)
Dynamic Range
ASSIGNABLE OUTPUT jacks (1 to 10): 102 dB (typ.)
MAIN OUTPUT jacks (L, R): 102 dB (typ.)
* Sample Rate: 48.0 kHz or 44.1 kHz
* Input Connector: INPUT 1 to 24 (Input sens: +4 dBu, 20 Hz to 20 kHz)
Crosstalk@ 1 kHz
INPUT jacks (1 to 24): -80dB (Input sens: +4 dBu, IHF-A, typ.)
ASSIGNABLE OUTPUT jacks (1 to 10): -88 dB (typ.)
MAIN OUTPUT jacks (L, R): -88 dB (typ.)
* Sample Rate: 48.0 kHz or 44.1 kHz
Nominal Input Level (Variable)
INPUT jacks (1 to 16): -65 to +4 dBu
INPUT jacks (17 to 24): -28 to +4 dBu
Input Impedance
INPUT jacks (1 to 16): 14 k ohms
Non Clip Maximum Input level
INPUT jacks (1 to 24): +22dBu (1 kHz, 20 k ohms load, typ.)
Nominal Output Level
ASSIGNABLE OUTPUT jacks (1 to 10): +4 dBu (Load impedance: 10 k ohms, typ.)
MAIN OUTPUT jacks (L, R): +4 dBu (Load impedance: 10 k ohms, typ.)
Main specifications
