Roland R-09 - Page 9

9
Apr. 2006 R-09
6. Flip up the tabs in the circled areas and remove the CENTER BOARD.
fig.center-board-remove_85
7. For the BOTTOM BOARD as well, remove while flipping up the tabs
holding the BOTTOM BOARD in place.
fig.bottom-board-remove_85
