48
Advanced Use
State of the D BEAM Indicators in Edit Mode
❍ When the setting is “0–127,” “0–10,” or “0–15,” “0–31.”
The minimum value (0) will be when the D Beam indicators are all dark, and the maximum value when they are
all lit. As you increase the value, the D Beam indicators will successively light from the bottom.
The setting will increase as you turn the [VIBRATO AND CHORUS] knob clockwise, and will decrease as you
turn it counterclockwise.
When you press the VIBRATO AND CHORUS [ON] button, this will return to the default setting.
❍ If the setting is an “ON or OFF” switch
This will be OFF (0) when all D Beam indicators are dark, and ON when they are all lit.
This will be ON when the [VIBRATO AND CHORUS] knob is turned to the right, and OFF when turned to the
left.
When you press the VIBRATO AND CHORUS [ON] button, this will return to the default setting.
❍ When the setting is “-5–0–+5,” “-6–0–+5,” “-100–0–+100,” or “-3–0–+3”
The lit location of the D Beam Type indicator shows the approximate value.
When the value is 0, the center D Beam Type indicator (RING MODULATOR indicator) will light.
D Beam Type indicators below the middle will indicate a negative value, and D Beam Type indicators above the
middle will indicate a positive value.
Turn the [VIBRATO AND CHORUS] knob clockwise to increase the value, or counterclockwise to decrease it.
When you press VIBRATO AND CHORUS [ON], this will return to the default setting.
Min Max
OFF ON
OFF ON
0Min Max
