Main
Specications
Printing/Cutting Area
Maximum Area
The printing or cutting area along the horizontal plane (the direction in which the carriages move) is deter-
mined by the position of the pinch rollers.
Maximum Area When Using Crop Marks
When crop marks are used, the printing or cutting area is reduced from the maximum area by an amount
equal to the crop marks.
Max. 1,600 mm
90 mm
Printing or cutting area
Pinch roller
10 mm 1.5 mm
75 mm
Max. 24,998 mm
75 mm
Printing or cutting coordinates origin
1.5 mm 10 mm
10 mm
12.5 mm
10 mm
12.5 mm
12.5 mm
10 mm
12.5 mm
10 mm
Printing or cutting area
Crop mark
Maximum area
