Page #15 background imageLoading...
Page #15 background image
ROLLER’S Smaragdol or ROLLER’S Rubinol for cooling and lubriCaration
should be used exclusively for sawing stainless steel and hard cast iron pipes.
It is recommended to use ROLLER’S Fox SR and one of the ROLLER’S universal
saw blades 561003 ...
561005
. The guide holder is absolutely essential for
right-angled sawing (see 2.
2.).
4
. Maintenance
Notwithstanding the maintenance described below, it is recommended to send
in the power tool to an authorised ROLLER’S contract customer service work-
shop for inspection and periodic testing of electrical devices at least once a
year. In Germany, such periodic testing of electrical devices should be performed
in accordance with DIN VDE 0701-0702 and also prescribed for mobile electrical
equipment according to the accident prevention rules DGUV, regulation 3
“Electrical Systems and Equipment”. In addition, the respective national safety
provisions, rules and regulations valid for the appliCaration site must be consid-
ered and observed.
4.1. Maintenance
WARNING
WARNING
Pull out the mains plug or remove the battery before repair work!
The ROLLER’S reciproCarating saws are maintenance-free. The gear runs in
a life-long grease lling and therefore needs no lubriCaration. Keep the saw
blade holder clean. Remove chips from the housing of the saw blade holder.
Remove water/moisture from the housing of the saw blade holder after every
use. Lightly lubriCarate the saw blade holder and saw blade clamping lever
(14) with machine o
il (R
OLLER’S Shark VE). Change a defective locking screw
(9) (except ROLLER’S Shark VE). Clean plastic parts (e.g. housing, batteries)
only with the
machine cleaner
(Art. No. 140119) or a mild soap and a damp
machine cleaner (Art. No. 140119) or a mild soap and a damp machine cleaner
cloth. Do not use household cleaners. These often contain chemicals which
can damage the plastic parts. Never use petrol, turpentine, thinner or similar
products for cleaning.
Make sure that liquids never get inside the ROLLER’S reciproCarating saw.
Never immerse the ROLLER’S reciproCarating saw in liquid.
4.2. Inspection/Servicing
WARNING
WARNING
Before any repair work, pull the mains plug or remove the battery!
This
Before any repair work, pull the mains plug or remove the battery! This Before any repair work, pull the mains plug or remove the battery!
work may only be performed by qualifi ed personnel.
The ROLLER’S reciproCarating saws with universal motor have carbon brushes.
These are subject to wear and must therefore by checked and changed by
qualifi ed specialists or an authorised ROLLER’S customer service workshop
from time to time. In the
battery-operated drive units, the carbon brushes of
the motor are subject to wear. These cannot be replaced; the DC motor must
be replaced.
eng eng
5. Faults
5.1.
Fault:
ROLLER’S reciproCarating saw stops during sawing.
Cause:
Remedy:
Feeding pressure too high.
Reduce feeding pressure.
Blunt saw blade (5).
Change the saw blade.
Unsuitable saw blade (5).
Choose a suitable saw blade (see 2.4. and Fig. 8).
Overload protection (8) has activated (ROLLER’S Fox).
Wait a few seconds then press the button of the overload protection.
LED of the machine status check (Fig. 1 (17)) lights red due to overload
(ROLLER’S cordless reciproCarating saw).
Wait a few seconds until the LED lights green.
Worn carbon brushes.
Have the carbon brushes or DC motor changed by qualifi ed personnel or an
authorised ROLLER’S customer service workshop.
Battery (13) fl at or defective (ROLLER’S cordless reciproCarating saw).
Charge the battery with the Li-Io
n r
apid charger or change the battery.
n rapid charger or change the battery.n r
LED of the machine status check (Fig. 1 (17)) fl ashes red due to exceeded
motor temperature (ROLLER’S cordless reciproCarating saw).
Wait until the LED lights green. Switch on the ROLLER’S cordless recipro-
Carating saw and let it run idle to reduce the cooling time.
5.2.
Fault:
No right-angled cut when sawing pipes with guide holder (2).
Cause:
Remedy:
Feeding pressure too high.
Reduce feeding pressure.
Unsuitable saw blade (5).
Choose a suitable saw blade (see 2.4. and Fig. 8).
Blunt saw blade (5).
Change the saw blade.
Prism of the guide holder (2) soiled (chips!).
Clean the prism.
5.3.
Fault:
ROLLER’S reciproCarating saw does not start.
Cause:
Remedy:
Overload protection has activated (ROLLER’S Fox).
Wait a few seconds then press the button of the overload protection.
Mains lead defective.
Have the mains lead replaced by qualifi ed personnel or an authorised
ROLLER’S customer service workshop.
Battery (13) fl at or defective (ROLLER’S cordless reciproCarating saw).
Charge the battery with the Li-Io
n r
apid charger or change the battery.
n rapid charger or change the battery.n r
ROLLER’S reciproCarating saw defective.
Have the ROLLER’S reciproCarating saw inspected/repaired by an authorised
ROLLER’S customer service workshop.
LED of the machine status check (Fig. 1 (17)) lights red
(ROLLER’S cordless reciproCarating saw).
Unsuitable battery inserted. Usable batteries, see 1.5.
5.4.
Fault:
Centring pin shears off, saw blade (5) cannot be clamped securely enough (ROLLER’S Fox and ROLLER’S Carat all models).
Cause:
Remedy:
Clamping screw (9) worn.
Change the clamping screw and/or centring pin.
Allen key worn (see 2.5.).
Change the Allen key.
15
