Installing Kick Plate Hooks and Handles, and Installing Kick Plate onto Bed Case
KICK PLATE BACK SIDE
K118A
Handle screw
K148C
K148C
K123 screw
K148C
K123
screw
K118A handle screw
Use K123 screws to install K148C kick plate hooks as shown.
Install MDH-L handles with K118A screws.
STEP 2
Install kickplate hooks onto the hook posts inside the bed case.
THAT IS ALL THERE IS TO IT!!! CONGRATULATIONS, YOUR NEW MURPHY BED IS NOW COMPLETE
IF YOU HAVE A MURPHY BED SOFA – Continue Set-up with instructions included in the Murphy Sofa
