Manual Brake Installation, Operation, and Maintenance Manual
Page 19
Figure 10. Upper Beam Clamp Adjusting Components.
LOWER TOGGLE PIN
ADJUSTING NUT
Figure 11. Proper Clearance Between the Upper Beam Clamp and the
Bed.
BEAM
BED
THE BEAM AND THE BED MUST BE IN
CONTACT AT THE CENTER OF THE MACHINE
EXAGGERATED VIEW OF GAP AT EACH END
OF THE MACHINE
THE GAP MUST BE EQUAL AT BOTH ENDS
BRAKE
CROWNING
ADJUSTMENTS
TOGGLE ANCHOR
