ROPER WHITNEY
OF ROCKFORD, INC.
2833 HUFFMAN BLVD
ROCKFORD, ILLINOIS 61103
815/962-3011
815/962-2227 FAX
RR
RR
R
OPER OPER
OPER OPER
OPER
WHITNEY/CONNECTICUTWHITNEY/CONNECTICUT
WHITNEY/CONNECTICUTWHITNEY/CONNECTICUT
WHITNEY/CONNECTICUT
FLOOR MODEL
MANUAL BENDING BRAKES
Page i
INSTALLATION, OPERATION,
AND MAINTENANCE
MANUAL
Version 2.1
FOR 16-18 GUAGE MATERIAL
* All steel construction — no castings
* Heavy tie rods for minimum deflection
* Removeable bending bar and angle
* Adjustable apron hinges
* Positive rear material gauge adjustment
* Positive clamping pressure adjustment
* Apron stop rod for repeat bends
* Replaceable bushings and hinge pin
* Long handles for extra leverage
* Work support angle bar for full capacity 1-inch minimum flange
* Improved leg design for lighter weight
