Rosemount 8800D Series User Manual

Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
A-36
Options
MultiVariable Options
Expanded
MTA
(5)
MultiVariable output with Integral Temperature Sensor
Hazardous Locations Certifications
Standard Standard
E5 FM Explosion-proof, Dust Ignition-proof ★
I5 FM Intrinsically Safe, Non-incendive ★
IE FM FISCO Intrinsically Safe
(6)
★
K5 FM Explosion-proof, Dust Ignition-proof, Intrinsically Safe, Non-incendive ★
E6 CSA Explosion-proof, Dust Ignition-proof ★
I6 CSA Intrinsically Safe, Non-incendive ★
IF CSA FISCO Intrinsically Safe
(6)
★
K6 CSA Explosion-proof, Dust Ignition-proof, Intrinsically Safe, Non-incendive ★
KB FM and CSA Explosion-proof, Dust Ignition-proof, Intrinsically Safe, Non-incendive ★
E1 ATEX Flameproof ★
I1 ATEX Intrinsic Safety ★
N1 ATEX Type n ★
ND ATEX Dust ★
IA ATEX FISCO Intrinsic Safety
(6)
★
K1 ATEX Flameproof, Intrinsic Safety, Type n, Dust ★
E7 IECEx Flameproof ★
I7 IECEx Intrinsic Safety ★
N7 IECEx Type n ★
IG IECEx FISCO Intrinsic Safety
(6)
★
K7 IECEx Flameproof, Intrinsic Safety, Type n ★
E3 China Flameproof ★
I3 China Intrinsic Safety ★
N3 China Type n ★
IH China FISCO/FNICO Intrinsic Safety
(6)
★
K3 China Flameproof, Intrinsic Safety, Type n ★
E4
(7)
TIIS Flameproof
★
E2 INMETRO Flameproof ★
I2 INMETRO Intrinsic Safety ★
IB INMETRO FISCO Intrinsic Safety ★
PlantWeb Control Functionality
Standard Standard
A01
(8)
Basic Control: Foundation Fieldbus Advanced Control Function Block Suite ★
Conduit Electrical Connector
Expanded
GE
(9)
M12, 4-pin, Male Connector (eurofast
®
)
GM
(9)
A size Mini, 4-pin, Male Connector (minifast
®
)
GN ATEX Flameproof A size, Mini 4-pin male connector (minifast)
Other Options
Standard Standard
P2 Cleaning for special services ★
C4
(10)
NAMUR alarm and saturation values, high alarm
★
CN
(10)
NAMUR alarm and saturation values, low alarm
★
T1 Transient protection terminal block ★
V5 External ground screw assembly
★
M5 LCD (Liquid Crystal Display) indicator ★
R10 Remote electronics with 10 ft (3,0 m) cable ★
Table A-29. Rosemount 8800D Vortex Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
