Rosemount 8800D Series User Manual

Reference Manual
00809-0100-4004, Rev BA
August 2010
Rosemount 8800D
4-14
Burst Option
Burst Option enables you to select the variables to broadcast over the burst
transmitter. Choose one of the following options:
PV–Selects the process variable for broadcast over the burst transmitter.
Percent Range/Current–Selects the process variable as percent of range and
analog output variables for broadcast over the burst transmitter.
Process vars/crnt–Selects the process variables and analog output variables
for broadcast over the burst transmitter.
Dynamic Vars–Burst all dynamic variables in the transmitter.
Xmtr Vars–Allows the user to define custom burst variables. Select variables
from the list below:
Burst XMTR Vars
Allows users to select and define Burst Variables.
XMTR Variable Slot
1
User selected Burst Variable 1.
XMTR Variable Slot 2
User selected Burst Variable 2.
XMTR Variable Slot 3
User selected Burst Variable 3.
XMTR Variable Slot 4
User selected Burst Variable 4.
Field Comm. 1, 4, 2, 3, 5
Volume Flow
Velocity Flow
Mass Flow
Vortex Frequency
Pulse Output Frequency
Totalizer Value
Process Temperature
Calculated Process Density
Electronics Temperature
Field Comm. 1, 4, 2, 3, 6
Field Comm. 1, 4, 2, 3, 6, 1
Field Comm. 1, 4, 2, 3, 6, 2
Field Comm. 1, 4, 2, 3, 6, 3
Field Comm. 1, 4, 2, 3, 6, 4

Rosemount 8800D Series Specifications

General

Type	Vortex Flow Meter
Measurement Principle	Vortex Shedding
Operating Temperature	-40 to 185°F (-40 to 85°C)
Storage Temperature	-40 to 185°F (-40 to 85°C)
Communication Protocols	FOUNDATION Fieldbus
Material	316 stainless steel
Fluid Type	Liquid, Gas, Steam
Line Size	1/2 to 8 inches (15 to 200 mm)
Approvals	ATEX, IECEx, CSA, FM
Output Signal	4-20 mA
Process Connection	Flanged, Wafer, Threaded
Electrical Connection	M20
Protection Rating	IP66
Mounting Style	Wafer, Flanged
