8. Airbags fail to work
Air valve for seat
side airbag
left air
valve
right air
valve
Troubleshooting
Analysis of causes：
Method of exclusion:
Picture 1 Picture 2
1.Air hose folded or fell off
2.Air pump is damaged
3.Mainboard is damaged
1.If part of the airbags fail to inflate,it indicates that the air compressor
functions well,check the air hoses with mentioned issue to see if they are folded or
fell off;
2. If air hose and airbags are good,use a multimeter Ω function to test air valve
connector(Fig.1 Air valve for seat side airbag ),if the black probe and red probe,the
black probe and yellow probe read between 160-170, air valve is good, otherwise the
air valve is damaged.
