Rotax 125 MAX evo Repair Manual

BRP-Rotax
REPAIR MANUAL
PREPARATION FOR INSTALLATION
Safety
instructions
ATTENTION
Clean and inspect disassembled parts and assemble them in accordance with the in-
structions. All screws and nuts must always be clean. Inspect surfaces and threads for
damage. In case of doubt use new screws and nuts.
REMOVING THE ENGINE FROM THE TRESTLE MOUNTING PLATE
Instructions Proceed as follows to remove the engine from the trestle mounting plate:
1. The engine is removed in reverse order of positioning.
See also Chapter Positioning the engine on the trestle mounting plate.
INSTALLATION OF THE ENGINE ON KART CHASSIS
Safety
instructions
m WARNING
Non-compliance can result in serious injuries or death!
Before installing the engine on the chassis the Installation and Operators Manual for
the engine and the installation instructions of the chassis manufacturer must be read
and understood.
For the Installation of the engine on kart chassis, see latest current Installation and Opera-
tors Manual of the engine type 125 MAX.
INSTALLATION OF THE FUEL LINE
Safety
instructions
m WARNING
Non-compliance can result in serious injuries or death!
When handling with fuel, do not smoke or allow open flames. Gasoline and gasoline va-
por are highly flammable and explosive under certain conditions.
m WARNING
Risk of fire and explosion!
Make sure that fuel will not splash onto hot engine components or equipment.
Effectivity: 125 MAX evo, Junior MAX
evo, Mini MAX evo, Micro MAX evo
Edition - February 01 2018 /Rev. 0
Chapter 9
Page 7
