Instructions Proceed as follows to install the fuel line:
1. The installation of the fuel line is identical to the removal, but in reverse order.
See also Removal of the fuel line
INSTALLATION OF THE BOWDEN CABLE
Instructions Proceed as follows to install the bowden cable:
1. The installation of the bowden cable is identical to the removal, but in reverse order.
See also Removal of the Bowden cable
INSTALLATION OF THE IGNITION SYSTEM
General See Figure: Ignition unit.
NNOOTTEE
On the sand-cast model the pick up for the ignition unit is fastened to the housing
with 2 M6x16 cyl. screws. On the die-cast model the pick up for the ignition unit is
fastened to the housing with 2 M6x16 TAPTITE screws (= self-tapping screw).
NNOOTTEE
If the two TAPTITE screws are installed in a previously used housing, make sure
that the screws are correctly positioned in the previously tapped threads in the
housing.
Instructions Proceed as follows to install the ignition system:
1. Position the pick up on the housing with the wiring harness terminal pointing in the direction
of the gearbox.
2. Fasten the pick up for the ignition system with the two cyl. screws or TAPTITE screws to the
specified tightening torque of 10 Nm (90 in.lb).
Chapter 9
Page 8
Effectivity: 125 MAX evo, Junior MAX
evo, Mini MAX evo, Micro MAX evo
Edition - February 01 2018 /Rev. 0
