Rotex RHYKOMB33AA Installer's Reference Guide

16 Technical data
Installer reference guide
106
RVLQ05+08CAV4 + RHYHBH05AA + RHYHBH/X08AA +
RHYKOMB33AA
ROTEX HPU hybrid
4P355635-1 – 2013.05
16.5.2 Technical specifications: Indoor unit
Technical specifications
Heating only type Reversible
type
Indoor units RHYHBH05 RHYHBH08 RHYHBX08
Connected to outdoor unit RVLQ05CAV3 RVLQ08CAV3 RVLQ08CAV3
Nominal input (indoor unit only) 75 W
Casing
Colour White
Material Pre-coated sheetmetal
Dimensions
Packing (H×W×D) 1240×528×262
Unit (H
(1)
×W×D) 902×450×164
Weight of machine (net) 33 kg 31.2 kg
Weight of machine (packed) 33 kg 34.4 kg —
Packing materials
Material Carton/EPS/PP (straps)
Weight 3 kg
PED
Category of unit Art. 3.3(*) Category I
Most critical part — Plate heat exchanger
Ps*V — 51 bar
Ps*DN —
Main components
Pump Type DC motor
Nr. of speed Inverter controlled
Nominal ESP unit Heating
(2)
51.8 kPa 19.2 kPa
Heating
(3)
55.7 kPa 26.0 kPa
Cooling
(7)
— 44.8 kPa
Cooling
(8)
— 26.5 kPa
Power input 45 W
Water side heat exchanger Type Brazed plated
Quantity 1
Water volume 0.9 l 1.3 l
Minimum water flow rate 5.0 l/min
Nominal water flow rate Heating
(2)
12.6 l/min 21.2 l/min
Heating
(3)
11.5 l/min 19.8 l/min
Cooling
(7)
— 15.4 l/min
Cooling
(8)
— 19.7 l/min
Maximum water flow rate
(4)
Heating 23.0 l/min 23.5 l/min
Insulation material Elastomeric foam
Expansion vessel Volume 10 l
Maximum water pressure 3 bar
Pre-pressure 1 bar
Water filter Diameter perforations 1
Material Body: copper+brass
Filter element: stainless steel
Water circuit
Piping connections Ø22 mm
Safety valve 3 bar
Manometer
(6)
No
Drain valve/fill valve No
Stop valves No
Air purge valve Yes
