basic operation (BRI/COL) by pressing both control
knobs together.
– (‘TEMP’) Temperature
Click the left knob to display the internal operating
temperature of AEOS. Note: if AEOS detects the
battery temperature rising to 58ºC or above, it
will display ‘too hot’ (touch any knob to clear the
message) and automatically cut the output down
to 25% to prevent overheating.
(Please only use high-quality battery systems with
AEOS such as the Rotolight 95Wh V-lock, which will
drive the light at full continuous power for 2-3 hours).
– (‘SRNO’) Serial Number
Use the right knob to active a scrolling display of
the serial number. Press the left knob to exit.
– (‘VERS’) Firmware Version
Click the left knob to display the firmware version
installed in your AEOS. Note: The firmware can be
updated if required by your Rotolight distributor
Click the left knob to return to MENU, alternatively
you can return to the basic operation (BRI/ COL) by
pressing both control knobs simultaneously.
– (‘DISP’) Display
Display mode allows the digital display to be set to
high or low brightness or ‘off’ to reduce power
consumption/increase battery life or for discrete
usage on set. Click the right knob to enter ‘DISP’.
Rotate either knob to select the display mode.
‘High’ – the display will be at full brightness.
‘Low’ – the display will be dim, reducing power
consumption.
‘Off’ – the display will automatically switch off
after 5 seconds unless a control is operated,
providing maximum power saving or discrete
operation on set.
Click the left knob to return to MENU, alternatively
SRNo
TEMP
VERS
DISP
