25”
OPERATING INSTRUCTIONS
Turn on any powered dust collection system before operating saw.
If sawdust accumulates in base of hood, tap sides of hood to loosen dust,
allowing the dust to be pulled into the ROUSSEAU 5000 dust port.
Note: Poor dust collection may be
caused by the exhaust port on some saws
directing chips over the top of the hood.
See Figure 3.
The chips can be redirected into the hood
using the correct sized 45 degree angle fitting
for your specific saw. See Figure 4.
Your local hardware store, plumbing supply store or vacuum repair
shop has this part. This fitting should redirect the exhaust for better
collection while still allowing the chips, dust and air to flow freely.
36”
50”
