11
Adjust the throttle trim so the carburetor is
completely closed at neutral and there is a little
gap between the servo arm and collar (Fig.
A:gap should be less than 1 mm).Use sub-trim
(refer to your transmitter instructions)if needed.
If throttle output arm is not close to its desired
neutral position after the binding process and
throttle cannot be centered using trim and sub-
trim, please take the following steps:
1. Make sure trim and sub-trim are set to “0”or
neutral.
2. Remove the servo output arm using a
Phillips screw driver and replace the arm in
correct orientation.
3. Trim the throttle as described above.
Throttle Trim
Notice:
Always ensure servo arm is parallel with the
vehicle center line at neutral and the gap in the
throttle linkage is less than 1 mm. Failure to do
so could result in engine malfunction causing
loss of control of the vehicle, resulting in property
damage and injury.
Installation Guide
SECTION B
Fig.A
1mm
