6
Charging The Receiver Battery
1. Remove the retaining clip and battery box
lid.
2. Remove the receiver battery from the
battery box.
3. Connect the receiver plug to the battery
charger.
4. Plug the battery charger into wall outlet.
Charge the battery for 8 hours. DO NOT
exceed 10 hours charge time.
5. Monitor battery while charging.
6. When the battery is fully charged: (a)
disconnect the battery and (b) remove the
battery charger from the wall outlet.
7. Place the receiver battery back in the
battery box and connect the battery plug to
the switch plug. The battery wire must be
neatly folded in front of the battery and the
foam block must be placed on top of the
wires.
8. Reinstall battery box lid and the retaining
clip.
Installation Guide
SECTION B
3
7
2
4
