Panama Corner Sofa Set
Assembly Instructions
Produced in China for A Mir & Co., Ltd.
© A Mir & Co., Ltd. 4 / 8
www.ro
y
alcraft.co.uk
Components, fixtures & fittings (not actual size)
Parts List
Part
No.
Diagram Qty.
Part
No.
Diagram Qty.
A
Corner/End Sofa
Backrest
3 PCS B
Corner/End Sofa Seat
3 PCS
C
Middle Sofa Backrest
2 PCS D
Middle Sofa Seat
2 PCS
E
Coffee Table Frame
1 PC F
Glass Top
1 PC
G
Middle Sofa Backrest
Cushion
2 PCS H
Corner/End Sofa
Backrest Cushion(Big)
3 PCS
