LoL
uPL
-60.0 °C 150 uPL
LoL 150.0 °C -60
HY5
oFF
20.0 °C 2
20.0 °C 0
0.1
-20.0
Min.
Max.
UNIT
DEFAULT
VALUE
A.LoL
A.uPL
A.dFL
A.HY5
A.typ
A.uPL °C -60
A.LoL 150.0 °C 150
0:00 99:00
0.1 20.0 °C
Ab5 rEF Ab5
A.dPo
99:00 min:sec 0:00
-60.0
0:00
D.drE
D.Pon
D.dPo
99:00
YE5
No
No
99:00 min:sec
Unit
°F °C
C.pon
C.Fo5
C.PPn
C.PPF
D.dur
D.int
D.dSP
RE
Lc.
Lc.
99:00 min:sec
99:00 min:sec
5nd
6 0
°C
0
0:00
0:00
0:00
0:00
0:00
Dpnt
No
YE5
No
CONFIGURATION PARAMETERS
COMPRESSOR PROTECTION PARAMETERS
DEFROST CONTROL PARAMETERS
ALARM CONTROL PARAMETERS
1:00
Delay time required for the compressor to restart following a stop.
d.inp
ddi
Display configuration in defrosting process (rE : Real temperature is displayed during defrost.
(Lc : During a defrosting process, last measured temperature value
is displayed before the defrosting process. This value remains constant until the end of defrosting.
Delay time for defrosting after power-up.
99:00
nd
Lght
Upper limit for setpoint
Differential cooling (hysteresis)
Offset value for cooling
Delay time for the compressor after power is on.
On time for the compressor output in the case of probe failure.
Off time for the compressor output in the case of probe failure
Defrost duration ( If d.dur = 0 selected, automatic and manual defrost is disabled ).
Time between 2 consecutive defrosts.
Delay time for display real temperature after defrost is over.
Defrost process with power. ( no = Defrost process is not started when power-up.
YE5 = Defrost process starts when power-up ).
Limit for upper alarm level. When A.tYP is changed, AuPL should be readjusted.
Limit for lower alarm level. When A.tYP is changed, ALoL should be readjusted.
Hysteresis alarm
Alarm configuration. ( Ab5 = Independent alarm. Alarm values are A.LoL and A.uPL .)
(rEF = Relative alarm. Alarm values are SET-A.LoL and SET+A.uPL.)
NOTE: Upper and Lower alarm level variables are determined according to the “ A.tYP ” parameter.
If A.tYP = A.b5 , A.LoL and A.uPL.
If A.tYP = rEF, LoL = SET-A.LoL and A.uPL.
Time delay to display alarm message after alarm is on.
Time delay to display alarm message after power is on.
dpo
CL
oP
Cl
1:00
0:00
2
1:00
1:00
1:00
1:00
1:00
hr:min
min:sec
0:00
0:00
0:10
hr:min
0:00
RSKEY PARAMETER TRANSFER
NOTE 1 : No power-up required for transfering the by using "RSKEY". For long battery
life, "RSKEY" must be disconnected from device after the transferring process.
NOTE 2 : Please specify at order “RSKEY” if required.
parameter
nd
d.5mt
Smart Defrost selection (no : Defrost counter (between 2 defrost duration) decrease irrespective of d.int
status of the compressor. YE5 : Defrost counter decreases as long as compressor work.).
No
YE5
No
baud
Adr5
19.20
1
off
Modbus slave device address for device
MODBUS COMMUNICATION PARAMETERS
Modbus communication speed ( Baud rate, 0 : oFF, 1 :1200, 2 : 2400, 3 : 4800, 4 : 9600, 5 :19.200 )
247
1
bps
9600
C.typ
Co
Co
HE
Control type selection ( HE = (*) heating control is selected, Co = Cooling control is selected.)
C.tYp parameter as HE is selected, the defrost function of the device is disabled.
0:00
Read
button
TRANSFERRING THE PARAMETERS FROM RSKEY TO DEVICE
While in "Running Mode", if key on device or “Read” button on “RSKEY” is pressed, appears on
display and parameters are read and transferred to the device. If the parameter transfer is successful, the " rEf "
message appears and the device begins to work with the loaded parameter values. If the parameters are wrong,
incorrect or " RSKEY " is faulty, " Err " message appears. Parameters will not be changed on device.
“dL” message
TRANSFERRING THE PARAMETERS FROM DEVICE TO RSKEY
While in "Running Mode", if key is pressed on device, appears on display and parameters are read
and transferred to the device. If process success, “ 5uc ” message appears. In case of failure, " Err" message
appears. Parameters will not be changed on device.
“uL” message
CONTROL PARAMETERS
Lower limit for setpoint
Digital input types. nd:Digital input unused. EA: External alarm. EA message flashes in the display. Output
unchanged. SA: Important external alarm. 5A message flashes in the display. Relay output is turned off. HC:
Control type. Ctyp parameter is changed.( If HE = Co, If Co = HE ) df: Defrost operation is started .
Digital input delay. The period of the digital inputs to be active.
Temperature unit
Decimal point (no= decimal point isn’t shown 22°C,YE5=decimal point is shown 22.3°C.)
Type of buzzer sound (6 different voice types can be selected. Alarm during 0 is chosen, the voice warning is
canceled.) For Relay-8A is valid.
Digital input polarity. cL = While a digital input contact is closed,it is activated.
oP= While a digital input is opened, it is activated.
1241045/46-E-01-161006
3/3
99:00 min:sec
99:00 min:sec
99:00 min:sec
0:00
99:00
