AMBER
Voltage Dropout
GREEN
Output OK
RED
Over Current
Mode Selection
Switch
RSG Engineering Limited Telephone : 01543 438800 Fax : 01543 438801 Email : sales@rsg-ontop.com Web : www.rsg-ontop.com
1:13
UNIVERSAL CONTROLLER PLUS (MCS-32) USER GUIDE V3 F : CONNECTION AND SWITCH DETAILS
F:9 LED Diagnostic Display
F : Connection and Switch Details
