RSG Engineering Limited Telephone : 01543 438800 Fax : 01543 438801 Email : sales@rsg-ontop.com Web : www.rsg-ontop.com
1:22
UNIVERSAL CONTROLLER PLUS (MCS-32) USER GUIDE V3 J : HANDSET AND SWITCH UNIT OPTIONS
J:3 Universal Multi-Way Maxi DIN/Flush Fit Switch Unit - 14 Small Buttons (MCS-F14)
J : Switch Unit Specification
Please Note: L = Latching M = Momentary, please tick the box next to the appropriate key number if required.
The key colour is created by the LED shining behind the key, please specify the colour required.
Keep words as short as possible and abbreviate long words, if an abbreviation is not stated we will insert a standard abbreviation.
Cable entry and button numbering will remain in the same position regardless of orientation please tick the appropriate box to specify cable entry.
Switch No. Legend (eg Front Spots) Colour L M
1
2
3
4
5
6
7
8
9
10
11
12
13
14
CABLE ENTRY RIGHT
CABLE ENTRY LEFT
I require cable entry on the RIGHT I require cable entry on the LEFT
J:4 Universal Multi-Way Maxi DIN/Flush Fit Switch Unit
2 Large + 12 Small Buttons
(MCS-F14)
Switch No. Legend (eg Front Spots) Colour L M
1
2
3
4
5
6
7
8
9
10
11
12
13
14
CABLE ENTRY RIGHT
CABLE ENTRY LEFT
I require cable entry on the RIGHT I require cable entry on the LEFT
J:5 Universal Multi-Way Maxi DIN/Flush Fit Switch Unit
1 Double + 12 Small Buttons (MCS-F14)
Switch No. Legend (eg Front Spots) Colour L M
1
3
4
5
6
7
8
9
10
11
12
13
14
CABLE ENTRY RIGHT
CABLE ENTRY LEFT
I require cable entry on the RIGHT I require cable entry on the LEFT
