Right speaker back
13. Output to left speaker
14. DC power socket
15. Sub-woofer output (3.5mm stereo jack)
16. Line-in audio input (3.5mm stereo jack)
17. Input level select
Right speaker front
8. Control knob (volume and source)
9. Status indicator light (see section 8)
10. Tweeter (high frequency driver)
11. Remote sensor
12. Woofer (low frequency driver)
2 Overview
8
10
9
16
17
15
14
13
11
12
short press = power
long press = source
