III. PARTS AND FUNCTIONS
Controls
Sleep
Dehumidification
Timer
Low wind
Continuous dehumidification
Child lock
High wind
Strong desiccant/dehumidification
Defrost
Full of water
Fan
%
Humidity
Installation
For efficient operation of the
dehumidifier, spacing are required as
shown below
Note:
In case TV sets, radio etc. Are disturbed
with noises, keep them apart form the
dehumidifier by 70 cm or more.
Transport handle
Controls
PUMP drain port
Power supply
Continue drain port
Water tank
Air intakes
Up 30 cm
Back: 30 cm
Right: 20 cm
Front: 20 cm
Left: 20 cm
