9
FE2-220150-025 700 220 2.5 1 2.7 2,270 11.4 14.3 14 15 11.3 6.3 9529 10557
FE2-220150-042 700 220 4.2 1 2.7 3,950 19.1 23.9 10 25 19.0 10.5 9530 10557
FE2-220150-063 700 220 6.3 1 2.7 6,050 28.6 35.8 8 40 28.5 15.8 9531 10557
FE2-220150-084 700 220 8.4 1 2.7 8,140 38.2 47.8 6 50 37.9 21.1 9532 10558
FE2-220150-126
1450
220 12.6 1 1.4 12,100 57.3 71.6 2 75 27.5 15.3 9533 10558
FE2-230150-028 700 230 2.8 1 2.7 2,480 12.2 15.3 12 20 12.6 7.0 9529 10557
FE2-230150-046 700 230 4.6 1 2.7 4,310 20.0 25.0 10 25 20.8 11.5 9530 10557
FE2-230150-069 700 230 6.9 1 2.7 6,610 30.0 37.5 8 40 31.2 17.3 9531 10557
FE2-230150-138 1450 230 13.8 1 1.4 13,200 59.9 74.9 2 80 30.1 16.7 9533 10558
FE2-380350-025 700 380 2.5 3 0.7 2,270 3.8 4.8 16 5 11.3 6.3 9529 10557
FE2-380350-042 700 380 4.2 3 0.7 3,950 6.4 8.0 16 10 19.0 10.5 9530 10557
FE2-380350-063 700 380 6.3 3 0.7 6,050 9.6 12.0 14 15 28.5 15.8 9531 10557
FE2-380350-084 700 380 8.4 3 0.7 8,140 12.8 16.0 12 20 37.9 21.1 9532 10557
FE2-380350-125 1450 380 12.5 3 0.7 12,100 19.0 23.8 10 25 27.3 15.1 9533 10557
FE2-380350-209 3000 380 20.9 3 1.0 20,300 31.8 39.8 8 40 22.0 12.2 9535 10557
FE2-400350-028 700 400 2.8 3 0.7 2,480 4.0 5.0 16 5 12.6 7.0 9529 10557
FE2-400350-046 700 400 4.6 3 0.7 4,310 6.6 8.3 16 10 20.8 11.5 9530 10557
FE2-400350-069 700 400 6.9 3 0.7 6,610 10.0 12.5 14 15 31.2 17.3 9531 10557
FE2-400350-093 700 400 9.3 3 0.7 8,900 13.4 16.8 12 20 42.0 23.3 9532 10557
FE2-400350-139 1450 400 13.9 3 0.7 13,200 20.1 25.1 10 30 30.3 16.8 9533 10557
FE2-400350-185 1450 400 18.5 3 0.7 17,800 26.7 33.4 8 35 40.3 22.4 9534 10557
FE2-400350-231 3000 400 23.1 3 1.0 22,200 33.3 41.6 8 45 24.3 13.5 9535 10557
FE2-415350-037 700 415 3.7 3 0.7 3,510 5.1 6.4 16 10 16.7 9.3 9537 10557
FE2-415350-075 700 415 7.5 3 0.7 7,240 10.4 13.0 14 15 33.9 18.8 9539 10557
FE2-415350-149 1450 415 14.9 3 0.7 14,500 20.7 25.9 10 30 32.5 18.1 9541 10557
FE2-415350-224 3000 415 22.4 3 1.0 21,800 31.2 39.0 8 40 23.6 13.1 9543 10557
FE2-440350-042 700 440 4.2 3 0.7 3,950 5.5 6.9 16 10 19.0 10.5 9537 10557
FE2-440350-084 700 440 8.4 3 0.7 8,140 11.0 13.8 14 15 37.9 21.1 9539 10557
FE2-440350-168 1450 440 16.8 3 0.7 16,300 27.5 34.4 8 35 36.6 20.4 9541 10557
FE2-440350-209 3000 440 20.9 3 1.0 20,300 27.5 34.4 8 35 22.1 12.3 9542 10557
TEMPERATURE
RISE
FE2 TECHNICAL DATA FOR 50 HZ ELECTRIC AIR HEATERS
o
F
o
C
NOTES:
2. Heater is functioning normally if at rated voltage the amp draw is within 10% of the value in this table.
3. Operation at lower voltages will result in reduced heat output and amp draw
4. Add “T” to model number when adding a built-in thermostat
5. Add “D” to model number when adding a built-in disconnect switch
6. Add “P” to model number when adding a built-in pilot light
7. Add “S” to model number when adding a 3-way switch
8. Add "U" to model number for units with continuous fan option
9. Add "A" to model number for units with stainless steel cabinet.
MODEL
VOLTAGE
(V)
NOTE
AIR FLOW
(CFM)
PHASE
NOMINAL
WATTAGE
(kW)
MAX.
MOTOR
NAMEPLATE
CURRENT
(A)
HEATER
WATTAGE
(W)
TOTAL
CURRENT
(A)
MINIMUM
CIRCUIT
AMPACITY
(A)
SUPPLY
WIRE
SIZE
(AWG)
MAXIMUM
FUSE SIZE
(A)
CORE
PART
NUMBER
CONTACTOR
PART
NUMBER
