RUKO 1601PRO - Assembly Guide; Component Replacements

1601 PRO User Manual
Copyright ©2021 Ruko All Rights Reserved.
20
Pull out all the plugs and remove the ESC upward. Replace with a new ESC.
9 Assembly Guide
9.1 Replace the ESC
Mind the orientation
Electronic equipment connection diagram
Front
Steering servo
Li-ion battery
Integrated ESC
Power switch
Headlight
Taillight
Motor
Front
