RUKO RS40e - RS10 Drilling Mechanism Parts; RS10 Drilling Unit Parts

12
GB I english
PRECISION TOOLS
Pos. Description Article no. Quantity
1 Gasket for gear box 611 1 501 1
2 Spindle wheel 43.0 x 12.0 611 1 502 1
3 Stud wheel 34.0 x 8.0 611 1 503 1
4 Pinion shaft 611 1 504 1
5 Gear bearing sign 611 1 505 1
6 Gear box 611 1 506 1
7 Bearing 6003-2 RS1 611 1 507 1
8 Bearing 6203-2 RS1 611 1 508 1
9 Conclusion plate 611 1 514 1
10 Gasket 25.0 x 40.0 x 7.0 611 1 515 2
11 Spindle M14 611 1 516 1
12 Adjusting washer 17.0 x 24.0 x 0.2 611 1 517 1
13 Needle bush HK1010 611 1 518 1
14 Pole ring 611 1 519 1
15 Rotor 611 1 520 1
16 Needle bush HK 0810 611 1 521 1
17 Stopper 611 1 522 1
18 Safety ring DIN 471 – 10.0 x 1.0 611 1 523 1
19 Safety ring DIN 471 – 28.0 x 1.5 611 1 524 1
20 Ball bearing 6001-2Z 611 1 525 1
21 Ball bearing 608 2Z 611 1 526 1
22 O-ring 22.0 x 2.5 – NBR 611 1 527 1
23 Brush holder compl. 611 1 528 2
24 Carbon brush compl. 6.3 x 10.0 x 18.0 611 2 551 2
25 Thread groove screw ZM 4.0 x 12.0 611 1 530 4
26 Screw DIN 7981 3.9 x 60.0 611 1 531 2
27 Screw DIN 7981 4.8 x 38.0 611 1 532 4
28 Spring washer B4 corrugated 611 1 533 4
29 Motor casing 611 2 501 1
30 Motor cover 611 2 502 1
31 Air conduction ring 611 2 507 1
32 Grease chamber 611 2 513 1
33 Cylindrical pin DIN 7 4.0 x 12.0 611 3 215 1
34 Screw DIN 7981 3.9 x 50.0 611 3 504 4
Pos. Description Article no. Quantity
35 Magnet 611 1 101 1
36 Solid 611 1 300 1
37 Sledge 611 1 304 1
38 Gear holder lower part 611 1 305 1
39 Gear holder top part 611 1 306 1
40 Cable pipe 611 1 307 1
41 Guide bead right 611 1 308 1
42 Guide bead left 611 1 309 1
43 Thoothed rack 611 1 310 1
44 Bearing bowl 611 1 311 2
45 Pinion shaft 611 1 312 1
46 Adapter for handle 611 1 313 1
47 Spacer 611 1 316 1
48 Front cover 611 1 319 1
49 Screw MF12 611 1 330 1
50 Plate MF12 611 1 331 1
51 DIN 7984 – M5 x 20,0 611 9 002 6
52 DIN 912 – M5 x 10,0 611 9 024 4
54 DIN 912 – M6 x 16,0 611 9 027 6
55 DIN 912 – M6 x 20,0 611 9 028 2
56 DIN 912 – M6 x 30,0 611 9 029 1
57 DIN 913 – M5 x 6,0 611 9 040 6
Drilling unit RS10
Drilling mechanism RS10
