RUKO RS40e - Page 21

21
GB I english
PRECISION TOOLS
Pos. Description Article no. Quantity
58 Spacer 611 1 316 1
59 Plate MF12 611 1 331 1
60 Magnet 611 2 101 1
61 Solid 611 2 200 1
62 Prop for cable pipe 611 3 210 1
63 Bearing bowl 611 3 212 2
64 Adapter for handle 611 3 216 1
65 Pinion shaft 611 3 217 1
66 Sledge 611 3 219 1
67 Toothed rack 611 3 222 1
68 Gear holder 611 3 223 1
69 Cable pipe 611 3 224 1
70 Screw MF12 611 3 226 1
71 Guide bead 611 3 228 2
72 Intermediate plate top 611 3 251 1
73 Intermediate plate bottom 611 3 252 1
74 Gliding plate 611 3 253 2
75 Pressure bolt 611 3 254 1
76 Thread liner 611 9 823 1
77 Pressure pin 611 3 256 1
78 Set screw DIN 913 – M5 x 6.0 611 9 001 5
79 DIN 7984 – M4 x 6.0 611 9 016 1
80 DIN 7984 – M8 x 16.0 611 9 020 6
81 DIN 912 – M6 x 12.0 611 9 026 5
82 DIN 912 – M6 x 16.0 611 9 027 4
83 DIN 7991 – M3 x 8.0 611 9 045 8
84 DIN 7984 – M5 x 20.0 611 9 052 7
85 DIN 965 – M4 x 16.0 611 9 059 2
86 DIN 912 – M8 x 20.0 611 9 063 4
87 Safety ring DIN 471 – 30.0 x 1.5 611 9 306 2
88 Cylindrical pin DIN7 5.0 x 12.0 611 9 510 2
89 Handle 30.0 mm 611 9 807 1
90 Handle 50.0 mm 611 9 808 1
91 Balance plate Ø 30.0/36.0 611 9 813 1
92 Handle M12 611 9 815 3
93 Clamping handle 611 9 816 1
Pos. Description Article no. Quantity
94 Circuitboard 611 2 404 1
95 Main cable 611 1 410 1
96 Ground cable magnet 611 1 411 1
97 Cables motor switch-magnet switch-plate 611 1 412 1
98 Cables motor switch-magnet switch-plate-plate 611 1 413 1
99 Cables motor swittch-plate 611 1 414 1
100 Cables capacitor motor 611 3 416 1
102 Front cover 611 4 401 1
103 Magnet switch 611 4 402 1
104 Motor switch 611 2 573 1
105 Back cover 611 4 408 1
106 Switch clockwise - counterclockwise 611 4 404 1
107 Resistance for revolution 611 4 405 1
108 Resistance for torque 611 4 406 1
109 Motor cable 611 4 415 1
110 DIN 7984 – M4 x 6.0 611 9 016 1
111 DIN 6797 – M4 611 9 402 1
Electrical system RS40e
Drilling unit RS40e
