Model: Eagle 2 Pro
Connection
5-36v in
GND
Video out
Audio out
VBAT+
UP
UP
DOWN
DOWN
L
R
Transmitter
5D-OSD menu cable
2 pin extension cord
Power in
GND
To VBAT+
* Unplug the 5D-OSD menu cable after OSD setting.
