2
1
One screw
One screw hole in glass
One screw hole in post
ASSEMBLY INSTRUCTION
• Start by planning where you want your
balustrade and make sure that the
surface is level.
• Start by erecting the glass panel section.
The end with pre-drilled holes in the
aluminium edging must be at the top.
• Place the panel between two posts.
• Now secure the panel using the 2
screws provided, one on each side
(diagram 1).
• Mark the four holes in the base of the
post on
the surface where the balustrade will
go (diagram 2). Move the panel and pre-
drill/drill into the surface.
SAFETY
Note that the maximum
permitted assembly height
above ground is 100 cm.
Hardened safety glass is not
qualified as a safety rail.
NOTE!
Max. 100 cm!
3
