英文/English
Wired Connection
Wake-up Switch Console Function
After connect successfully, press [ ] Home button on Controller can wake up and
reconnect the sleep Switch console.
Click [ ] Setting on Switch Controllers and Sensors then click Pro Controller
Wired Connection. Please make sure this option state is ON.
OTG Adapter
*Before using the wired connection, please make sure the
Controller is OFF or in sleeping state.
❶ Connect the power-off Controller with Switch
console by USB cable with Type-C OTG.
❷ Connect successfully when LED indicator flash.
- Switch Console:
*Before using the wired connection, please make sure the
Controller is OFF or in sleeping state.
❶ Connect the power-off Controller with Switch dock by USB cable.
❷ Connect successfully when LED indicator flash.
- Switch Dock:
USB Port of Switch Dock
Reset Function
Attentions
英文/English
When the controller has a major function problem, frozen action buttons, dead halt
or other abnormalities, please press the Power button on back of Controller to restart.
Avoid strong vibration, don't disassemble, refit or repair on your own.
Avoid water or other liquid in controller, it may affect the performance of the controller.
Don't keep in humid, high temperature or soot place.
Keep away from fire, the built-in Lithium battery has danger of explosion.
Children should be under adult’s supervision to use this product.
Please connect with after-sales service when you have suggestion or operation
problem.
Charging Function
Sleeping Mode
英文/English
Reconnect State
The First Pairing State
Working State
30 seconds without connection
60 seconds without connection
5 mins without any opperations
Controller State Enter Sleeping State
Using a standard USB 5V input, the controller will be fully charged time in 2-3 hours.
Working State
Power OFF
Battery State
Indicator State
Low Battery
Flash
Flash
Keep ON
OFF
Flash
Charging
Charging
Fully Charged
Fully Charged
NFC Function
TURBO Function
英文/English
Using Instructions:
When the Controller connected with Switch console by
Bluetooth, if the game support Amiibo function, place
the Amiibo above the PXN logo can activate the tool.
Setting buttons for TURBO function: / / / / L / R / ZL / ZR
The Controller is built in NFC reader chip, support to
read Amiibo.
(Note: Recommend to use genuine Amiibo)
Manual TURBO
After the first setting, hold press this setting
button can launch TURBO manually
After the second setting, the setting button
will automatically launch TURBO
After the third setting, the TURBO function
will be cleared
Clear all button TURBO function
Auto-TURBO
Clear TURBO
Setting
Clear All TURBO
Setting
Setting Button
Setting Button
Setting Button
Under Manual TURBO：The LED indicator flash when hold press setting button.
Under Auto-TURBO ： The LED indicator flash quickly.
ZR
R
ZL
L
HOME Button
LED Indicators
TURBO Button
Type-C Interface
Power Button
Screenshot
Button
Product Overview
英文/English
MADE IN CHINA
210-130178
Rating
:
5V 26mA
Using on PC
英文/English
*Before using the wired connection, please make sure the Controller is OFF or in sleeping state.
❶ Connect the Controller with PC by USB cable.
❷ The PC will prompt new hardware and install automatically, connect successfully
when LED2 indicator flash.
Wired Connection
PC
LED2 Flashes
❶
❷
Function inspection is available when connect with computer. The specific steps
show below:
Open Control Panel Devices and Printers Right mouse click Controller icon
Game Controller Setting, click Properties Testing.
Controller Inspection on PC
User Manual
Product Specifications
英文/English
Produce Model
Connect Type
Working Power
Packaging Size
Product Size
Unit Weight
Usage Temperature
PXN-9607 X
Wireless / Wired Connection
Appr. 185*172*75 mm
Appr. 153*125*55 mm
10-40℃
Appr. 211g
Usage Humidity 20～80%
Built-in 550mAh Lithium Battery
Working Current 5V 26mA
Adjustable Vibration
Controller Calibration Function
英文/English
①
Press [ L3+R ] enter calibration mode, 4 LED indicator on Controller flash alternately.
②
Put the Controller on horizon desk, press [ ] button on Controller.
③
Release button, the Controller will automatically calibrate in 3 seconds.
OFF No Vibration
Low Weak Vibration
Medium Medium Vibration
High High Vibration
When the Controller occurs disorder or joystick problem, can use calibration
function to fix.
Hold press the [ ] button on Controller and operate the UP/Down of left
joystick at same time to adjust vibration level, default vibration level is medium
when connect. Vibration adjustment has memory function.
OFF
High
L
L
- Compatible Platforms: Switch Console/ PC
- Support System: Windows 7/8/10
System Requirement
英文/English
Switch Console
Wireless Connection
❷ Press [ ] Power button of Controller for 3 seconds to pair, 4 LED indicators flash orderly
and enter pairing state.
❸ Connect successfully when LED indicator keep ON, then press
[
]
Home button to back
to homepage.
Change Grip/Order
❶ Click [ ] Controller Change Grip/Order on Switch screen.
Controller
Controller
Change Grip/Order
Search handle
How to match the new handle
OFF
No other handles connected
Power ON
Button Operation Function Instruction
Wake-up
Controller
Wake-up
Console
Power OFF
Press [ ] Power button for
3 seconds
Power on and enter pairing
Can wake up sleep controller
and reconnect
Can wake up sleep Switch console
and reconnect
Press shortly can power OFF the
Controller and reset setting
Can use wake-up controller/console
function to reconnect under Controller
oFF state
Short press [ ] HOME button
on Controller
Short press [ / / / /
L / R / ZL / ZR / / ]
button on Controller
Short press [ ] Power button
Power and Wake-up
英文/English
