Ryobi 11A-545D034 - Page 17

17
Model 545
Ref.
No.
Part No. Part Description
1.
749-1092A Upper Handle
2.
747-1161A Control Handle
3.
720-0279 Handle Knob
4.
710-1205 Rope Guide
5.
710-1174 Carriage Bolt 5/16-18 x 2”
6.
736-0451 Shoulder Washer.320 ID x.930 OD
7.
720-0284 Wing Nut
8.
749-0928A Lower Handle
9.
746-0946 Control Cable
10.
664-0084 Grass Bag
11.
747-04080 Grass Catcher Frame
12.
714-0104 Hairpin Clip
13.
731-04134 Grass Bag Door
14.
732-0700 Wire Rod
15.
731-1236 Trail shield
16.
750-04162 Spacer.390 O.D. x.810 I.D. x.950”
17.
732-04090 Door Spring-RH
18.
687-02032 Handle Brkt. w/Adj Ass’y Comp- LH
687-02034 Handle Brkt. w/Adj Ass’y Comp- RH
19.
734-1861 Rear Wheel Assembly 14 x 2
20.
787-01104 Deck 21”
21.
710-0654A Hex Washer Screw 3/8-16 x 1.0
22.
736-0270 Bell Washer.265 ID x.75 OD
23.
710-0599 Hex Washer Screw 1/4-20 x.500
24.
712-0431 Hex Lock Nut 3/8-16
25.
782-5004A Rear Baffle - RH
26.
782-5003 Rear Baffle - LH
27.
710-1017 Tap Screw 1/4-14 x.625.
28.
710-0703 Hex Carriage Screw 1/4-20
29.
687-02033 Handle Bracket Assembly - RH
687-02031 Handle Bracket Assembly - LH
30.
710-0286 Machine Screw 1/4-20 x.500
31.
710-0896 Hex Washer Screw 1/4-14 x.625
32.
710-0216 Hex Cap Screw 3/8-16 x 1.0
33.
17488A Pivot Bar - RH
17489A Pivot Bar - LH
34.
738-0507B Shoulder Screw
35.
736-0105 Spring Washer.375 ID x.870 OD
36.
732-0866 Spring Lever
37.
736-0182 Wave Washer.500 ID x 1.0 OD
38.
736-0272 Flat Washer.510 ID x 1.37 OD
39.
738-0481A Shoulder Screw
40.
14578 Front Height Adjuster - RH
14579 Front Height Adjuster - LH
41.
734-1978 Front Wheel Assembly 8 x 2
42.
712-0431 Flange Lock Nut 3/8-16
43.
782-5002A Front Baffle
44.
732-1014 Torsion Spring
45.
747-0710 Hinge Pin
46.
17032A Hinge Mounting Bracket
47.
687-02055 Mulching Plug Ass’y Complete
48.
748-0376C Blade Adapter
49.
742-0741 21” Mulching
50.
736-0524A Blade Bell Support
51.
710-1044 Hex Cap Screw 3/8-24 x 1.5
52.
15261A Height Adjustment Plate
53.
720-0426 Height Adjustment Knob
54.
15262B Pivot Bar
55.
732-0404 Spring Lever
56.
738-0102 Shoulder Bolt
57.
747-0996 Chute Door Pivot Rod
58.
731-04177 Side Discharge Deflector
59.
732-04089 Door Spring - LH
60.
712-3005 Flange Lock Nut 3/8-16
61.
712-0397 Wing Nut
62.
720-0312 Foam Grip
63.
787-01113 Grassbag Mntg Brkt - Hardtop
64.
710-0896 Hex Washer Screw 1/4-14 x.625
65.
731-04299 Hard Top w/Logo and Indicator
731-04300 Hard Top w/Logo
731-04301 Hard Top w/Indicator
731-04302 Hard Top
66.
731-0981A Hub Cap
67.
736-0504 Wave Washer
68.
731-2626 Bail Cover
69.
731-1523 Front End Cover
Ref.
No.
Part No. Part Description
