Ryobi CSB133L Repair Sheet

3
KEY PART
NO. NUMBER DESCRIPTION QTY
1 940221050 CORD TAG LABEL FOR CIRCULAR SAW .. 1
2 940304502 LOGO LABEL (REAR) ............................. 1
3 940976262 DATA LABEL ........................................... 1
4 940266016 CUTTING DEPTH LABEL ........................ 1
5 681323001 BLADE (20T) ........................................... 1
6 941361002 CORD TAG LABEL FOR LASER ............. 1
7 940976269 LASER LABEL ........................................ 1
8 940304501 LOGO LABEL (FRONT) ........................... 1
9 630805010 WRENCH (14 mm) .................................. 1
10 562802001 BUMPER ................................................. 1
11 550423004 SPACER .................................................. 1
12 661548001 SCREW (M6 x 1 mm) .............................. 1
13 200677001 LOWER BLADE GUARD SUPPORT
w/OUTPUT SHAFT
AND BEARING ASSEMBLY .................... 1
14 660311006 SCREW (10-24 x 1/2 in.) ......................... 5
15 514310001 SLEEVE ................................................... 1
16 692039001 TORSION SPRING .................................. 1
17 632417001 SLEEVE FOR LOWER GUARD ............... 1
18 641515001 LOWER GUARD ...................................... 1
PARTS LIST (FIGURE A)
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding
your CIRCULAR SAW or when ordering repair parts.
19 680778002 RETAINING RING .................................... 1
20 680774010 INNER FLANGE BUSHING ..................... 1
21 680775001 OUTER BLADE WASHER ....................... 1
22 680776001 BLADE WASHER .................................... 1
23 660124001 BLADE BOLT .......................................... 1
24 516871003 LOWER BLADE GUARD HANDLE .......... 1
25 680980003 ROLL PIN ................................................ 1
26 301124006 DEPTH ADJUSTMENT KNOB ................ 2
27 680771002 WASHER .................................................2
28 301124007 EDGE GUIDE KNOB ............................... 1
29 660112006 SCREW (8-32 x 9 mm) ............................ 1
30 660106007 HEX NUT (8-32) ...................................... 1
31 660104010 CARRIAGE BOLT (1/4-20 x 5/8 in.) ......... 1
32 660104002 CARRIAGE BOLT (1/4-20 x 3-3/4 in.) ..... 1
33 300530028 BASE ASSEMBLY ................................... 1
NOT SHOWN
200673001 OPTIONAL VACUUM ADAPTERS
w/SCREWS ............................................. 1
987000327 OPERATOR’S MANUAL (961022008)
2-16-12
(REV:10)
KEY PART
NO. NUMBER DESCRIPTION QTY
WARNING: Improper repair of a double insulated tool can result in damages to the double insulation system possibly causing electrical shock
or electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized
Service Center. For the service center nearest you call 1-800-525-2579.
RYOBI 7-1/4 in. LASER CIRCULAR SAW – MODEL NO. CSB133L
