Ryobi CSB133L Repair Sheet

5
PARTS LIST (FIGURE B)
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding
your CIRCULAR SAW or when ordering repair parts.
1 660208052 SCREW (M4 x 16 mm) ........................................ 9
2 516878001 END COVER .......................................................1
3 660140002 SCREW (8-16 x 12.7 mm) ..................................3
4 630801001 CLAMP ...............................................................2
5 290075001 BRUSH TUBE ASSEMBLY .................................2
6 660311005 SCREW (10-24 x 1-1/8 in.) .................................2
7 516877004 MOTOR HOUSING .............................................1
8 660311004 SCREW (10-24 x 3/4 in.) .....................................2
9 550339001 RUBBER PLUG ..................................................1
10 741702001 FIELD ASSEMBLY ..............................................1
11 660101002 SCREW (M0.170 x 1.875 in.) ..............................2
12 551054001 BAFFLE ..............................................................1
13 202001001 ARMATURE ASSEMBLY (INC. KEY NOS. 14-17)..1
14 680966004 BALL BEARING (608ZZ) ..................................... 1
15 681037001 CUPPED WASHER .............................................1
16 680336001 RETAINING RING ...............................................1
17 681053001 BALL BEARING (CW6001) .................................1
18 516879001 FRONT HANDLE.................................................1
19 660312001 SCREW (8-32 x 3/8 in.) .......................................1
20 340875001 LASER HOUSING COVER ..................................1
21 660559001 SCREW (M3.5 x 10 mm) ..................................... 3
22 517010001 LASER HOLDER ................................................. 1
23 340876001 LASER WIRE COVER .........................................1
24 516870001 SPINDLE LOCK BUTTON...................................1
25 550421007 SPINDLE LOCK SHAFT ......................................1
26 680773001 SPRING ..............................................................1
27 672017001 SPRING ..............................................................1
28 302836001 LASER ASSEMBLY ............................................. 1
29 200678001 UPPER BLADE GUARD ......................................1
30 660859002 SCREW (M4 x 8 mm) .......................................... 1
31 690427002 RACK SHAFT LOCK ........................................... 1
32 200679001 HANDLE ASSEMBLY .......................................... 1
33 5532203 TRIGGER ............................................................1
34 280095004 CIRCUIT BOARD ASSEMBLY ............................1
35 680800003 SPRING ..............................................................1
36 7621301 SWITCH .............................................................. 1
37 770407051 LEAD (BLACK) ....................................................1
38 770408020 LEAD (WHITE) .....................................................1
39 690331002 TERMINAL BLOCK ............................................. 1
40 290251012 LIVE INDICATOR.................................................1
41 516872001 LASER SWITCH..................................................1
42 516915001 INDICATOR COVER ............................................1
43 6620613 SCREW (M3.5 x 10 mm) ..................................... 2
44 6933702 CORD CLAMP ....................................................1
45 5927401 BEND RELIEF .....................................................1
46 730372011 POWER CORD ...................................................1
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
WARNING: Improper repair of a double insulated tool can result in damages to the double insulation system possibly causing electrical shock
or electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized
Service Center. For the service center nearest you call 1-800-525-2579.
RYOBI 7-1/4 in. LASER CIRCULAR SAW – MODEL NO. CSB133L
