Ryobi P271 - Page 33

13
E
D
B
C
A
Fig. 7
A - Mag Tray™ (screw holder) [Mag Tray™
(compartiment pour vis), Mag Tray™
(compartimiento para tornillos)]
B - Double-ended bit (embout doubles, punta de
destornillador dobles)
C - Bit storage (rangement d’embouts,
compartimiento de brocas)
Fig. 8
RIGHT / CORRECT / FORMA CORRECTA
A - Keyless chuck (mandrin sans clé,
portabrocas de apriete sin llave)
B - Unlock (release) [unlock (libération), unlock
(aflojar)]
C - Chuck jaws (mors du mandrin, mordazas
del portabrocas)
D - Drill bit (embout, broca)
E - Lock (tighten) [lock (blocage), lock
(apretar)]
Fig. 9
WRONG / INCORRECT /
FORMA INCORRECTA
Fig. 10
LEVEL TOP VIEW / VUE DE DESSUS DE
NIVEAU / VISTA SUPERIOR DE NIVEL
A - Chuck jaws (mors du mandrin, mordazas del
portabrocas)
B - Mallet (maillet, mazo de goma)
C - Keyless chuck (mandrin sans clé, porta
brocas de apriete sin llave)
D - Hex key (clé hexagonale, llave hexagonal)
Fig. 11
Fig. 12
A - Screwdriver (tournevis, destornillador)
Fig. 13
A - Mallet (maillet, mazo de goma)
B - Hex key (clé hexagonale, llave hexagonal)
C
B
A
D
A
B
A
B
A
A
C
A - Level (niveau, nivel)
