RYOBI 18 VOLT DC CAULKING GUN – MODEL NUMBER P310
3
1 6620614
* SCREW (M3.5 X 14 mm PAN HD.) .................. 3
2 810203001 SPEED POTENTIOMETER .............................
2
3 6627201
* SCREW (M4 X 14 mm BINDING HD.) ............. 9
4 940078057 DATA LABEL ....................................................
1
5
200202324 HOUSING WITH LABEL ASSEMBLY
(INC. KEY NOS. 4, 22 and 37) ......................... 1
6 660203027
* SCREW (M3 X 8 mm PAN HD.) ....................... 1
7 860260001 CIRCUIT BOARD ...........................................
1
8
660203009 * SCREW (M3 X 14 mm PAN HD.) ..................... 5
9 640796001 RACK
.............................................................. 1
10 760384001 MICRO SWITCH .............................................. 1
11 660169038 * SCREW (M4 X 6 mm SOC. HD.) ..................... 1
12 671527001 PIN ................................................................... 1
13 512790001 RACK HANDLE ............................................... 1
14 660219007 * SCREW (M5 X 15 mm PAN HD.) ..................... 1
15 512789001 TRIGGER LOCK BUTTON .............................. 1
16 561200001 MOTOR COVER .............................................. 1
17 660211013 * SCREW (M3 X 4 mm PAN HD.) ....................... 1
18 830235001 POWER MOSFET ........................................... 1
19 631289001 HEAT SINK ...................................................... 1
20 342787001 SPEED CONTROL DIAL KNOB ...................... 1
21 9002711 LANYARD ....................................................... 1
22 940114107 LOGO LABEL .................................................. 1
23 760307001 SWITCH ........................................................... 1
24 512905001 FIELD ............................................................... 1
25 830223001 VOLTAGE REGULATOR .................................. 1
26 300001044 CONTACT PLATE HOLDER ............................ 1
27 6621106 * SCREW (M3 X 6 mm PAN HD.) ....................... 1
28 631279001 TUBE HOLDER .............................................. 1
29 940230100 WARNING LABEL ........................................... 1
30 660409001 * SCREW (M4 X 6 mm) ...................................... 1
31 512830001 PLUNGER ....................................................... 1
32 631286001 PLUNGER ....................................................... 1
33 631288001 RING ................................................................ 1
34 200292003 PLUG IN LANYARD ......................................... 1
35 671521001 TRIGGER SPRING .......................................... 1
36 512788001 TRIGGER ........................................................ 1
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
CAULKING GUN or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
