RYOBI 18 VOLT DC CAULKING GUN – MODEL NUMBER P310
5
1 670608001 C-RING ..................................................................................................................... 2
2 512795001 SHIFT GEAR .............................................................................................................
2
3 300215004 GEAR CASE ASSEMBLY .........................................................................................
1
4 671575001
CARRIER .................................................................................................................. 1
5 512793001 PLANETARY GEAR .................................................................................................
6
6
610463001 SOLAR GEAR ........................................................................................................... 1
7 300114019 GEAR TRAIN HOUSING ASSEMBLY ....................................................................... 1
8 671577001 WASHER ................................................................................................................... 1
9 6621106 * SCREW (M3 X 6 mm PAN HD.) ................................................................................ 2
10 6702801 SPRING WASHER .................................................................................................... 2
11 512792001 MOTOR BRACKET ................................................................................................... 1
12 660010003 * SCREW (M3 X 16 mm PAN HD.) .............................................................................. 6
13 230074007 MOTOR ASSEMBLY ................................................................................................. 1
14 300763002 GEAR HOUSING COVER ASSEMBLY ..................................................................... 1
15 610459001 GEAR ......................................................................................................................... 1
16 512796001 RING GEAR .............................................................................................................. 1
17 620354001 CARRIER SHAFT ..................................................................................................... 1
18 610461001 PLANETARY GEAR .................................................................................................. 6
19 671590001 SPRING .................................................................................................................... 1
20 671576001 CLUTCH ................................................................................................................... 1
21 610462001 RING GEAR .............................................................................................................. 1
22 610464001 SOLAR GEAR ........................................................................................................... 1
23 620355001 GEAR SHAFT ........................................................................................................... 1
24 680574001 WASHER ................................................................................................................... 1
983000592 OPERATOR’S MANUAL (960223391)
983000592R REPAIR SHEET (REV:03)
04-14-05
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
CAULKING GUN or when ordering repair parts.
Key Part
No. Number Description Qty
PARTS LIST
