RYOBI 18 VOLT TRIMMER – MODEL NUMBER P600
3
1 200202321 HOUSING ASSEMBLY W / LABELS (INC. KEY NOS. 2-6) ....................... 1
2 6620805 * SCREW (M4 X 16 mm PAN HD.) .............................................................. 8
3 940078058 DATA LABEL ............................................................................................. 1
4 5605513 FOAM RUBBER ........................................................................................ 4
5 940114108 LOGO LABEL ........................................................................................... 1
6 940299506 SCALE LABEL .......................................................................................... 2
7 270017056 SWITCH ASSEMBLY ............................................................................... 1
8 5991501 MOTOR BACK RING ................................................................................ 1
9 200315001 MOTOR & OUTPUT SHAFT &
LOCK PIN ASSEMBLY (INC. KEY NOS.10-24) ........................................ 1
10 7439401 MOTOR .................................................................................................... 1
11 640882001 MOTOR BASE .......................................................................................... 1
12 6796001 SPRING WASHER .................................................................................... 2
13 6621902 * SCREW (M5 X 12 mm PAN HD.) .............................................................. 2
14 640881001 BEARING HOLDER TOP COVER ................................................................ 1
15 6702801 SPRING WASHER .................................................................................... 2
16 6621101 * SCREW (M3 X 8 mm PAN HD.) ................................................................ 2
17 620365001 OUTPUT SHAFT ....................................................................................... 1
18 671608001 BALL BEARING ........................................................................................ 1
19 6725101 RETAINING RING ...................................................................................... 1
20 670230003 BUSHING ................................................................................................. 1
21 680661001 CURVED WASHER ................................................................................... 1
22 6723101 SPRING .................................................................................................... 1
23 670229002 SHAFT LOCK PIN ................................................................................... 1
24 512947001 LOCK PIN CAP ......................................................................................... 1
25 6904501 COLLET (1/4 in.) ....................................................................................... 1
26 690043002 COLLET NUT ............................................................................................ 1
27 200234005 BASE ASSEMBLY (INC. KEY NOS. 28-36) ............................................... 1
28 690401002 SPRING PIN ............................................................................................. 1
29 640708003 CLAMP LEVER ......................................................................................... 1
30 671352001 SQUARE WASHER ................................................................................... 1
31 620319001 ADJUST SCREW SHAFT .......................................................................... 1
32 670060001 WASHER .................................................................................................. 1
33 6797401 NYLON INSERT NUT ................................................................................ 1
34 342073001 BASE SUPPORT ...................................................................................... 1
35 512047002 SQUARE BASE ......................................................................................... 1
36 660279004 * SCREW (M4 X 12 mm FLAT HD.) ............................................................. 4
37 690604002 WRENCH .................................................................................................. 1
38 200292003 PLUG IN LANYARD .................................................................................. 1
39 200334001 WOODWORKING SUBBASE (NOT SHOWN) ......................................... 1
983000600 OPERATOR’S MANUAL (960223392)
983000600R REPAIR SHEET (REV:03)
03-09-06
PARTS LIST
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your TRIMMER or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
