9 — English
LINE CUT-OFF BLADE
See Figures 11 - 12.
WARNING:
The line cut-off blade on the grass deector is sharp.
Avoid contact with the blade. Failure to avoid contact
can result in serious personal injury.
This trimmer is equipped with a line cut-off blade on the grass
deector. For best cutting, advance line until it is trimmed to
length by the line cut-off blade. Advance line whenever you
hear the engine running faster than normal, or when trimming
efciency diminishes. This will maintain best performance
and keep line long enough to advance properly.
This trimmer is currently set at the 10 in. cutting swath. To
extend operational battery life, the cutting swath can be
reduced to 8 in.
To adjust to a cutting swath of 8 in.:
Remove the battery pack.
Loosen the blade screw then rotate the line cut-off
blade180°.
NOTE: Wear gloves when working with the cut-off blade.
Tighten the blade screw.
Reinstall battery pack.
EDGING
See Figures 13 - 14.
Remove the battery pack.
Depress the latches on each side of the lawn trimmer.
Rotate the lower end of the tool to the edging position.
Make sure the latches snap into place and the lower end
of the tool is secured before beginning operation.
Reinstall battery pack.
For Trimmer Operation:
Remove the battery pack.
Depress the latches on each side of the lawn trimmer.
Rotate the lower end of the tool to the trimmer position.
Make sure the latches snap into place and the lower end
of the tool is secured before beginning operation.
Reinstall battery pack.
WARNING:
Always hold the lawn trimmer away from the body keep-
ing clearance between the body and the lawn trimmer.
Any contact with the lawn trimmer cutting head while
operating can result in serious personal injury.
WARNING:
Never stand directly in the path of the cutting line while
edging. Always stand to the left of the grass deector to
avoid thrown debris, which could result in serious personal
injury.
OPERATION
