Ryobi RA-ACDDU1840 - Page 2

Fig. 1
1
6 1
2
3
4
5
7
3
8
DESCRIPTION
1. Handle
2. Regulated pressure gauge
3. Quick connect coupler
4. Pressure relief valve
5. Check valve
6. Tank pressure gauge
7. Pressure regulator knob
8. Wheel
9. Air lter assembly
10. Reset button
11. Air tank
12. Rubber foot
13. Hex nut
14. Flat washer
15. Bolt
16. Axle bolt
17. Wheel axle cover
18. To close
19. Quick connect air tting
20. Quick coupler
21. On
22. Off
23. To open
24. Drain valve lever
25. Air lter housing
26. Air lter
27. Air lter cover
28. Wing nut
Fig. 2
Fig. 3
12
14
15
13
14
Fig. 3 Fig. 4
Fig. 6
Fig. 5
14
14
13
1716
1
8
9
11
8
12
9
10
