exposed wires and cut or worn insulation.
WARNING
Keep the extension cord clear of the working area.
Position the cord so that it will not get caught on
lumber, tools, or other obstructions while you are
working with a power tool. Failure to do so can result
in serious personal injury.
WARNING
Check extension cords before each use. If damaged
replace immediately. Never use the product with a
damaged cord since touching the damaged area
could cause electrical shock resulting in serious injury.
ELECTRICAL CONNECTION
This product is powered by a precision-built electric
motor. It should be connected to a power supply that is
230-240 V, AC only (normal household current), 50
Hz. Do not operate this product on direct current (DC). A
substantial voltage drop will cause a loss of power and
the motor will overheat. If the product does not operate
when plugged into an outlet, double check the power
supply.
SPEED AND WIRING
The no-load speed of this product is approximately 11
m/s. This speed is not constant and decreases under
a load or with lower voltage. For voltage, the wiring in a
shop is as important as the motor’s input power rating.
A line intended only for lights cannot properly carry a
power tool motor. Wire that is heavy enough for a short
distance will be too light for a greater distance. A line
that can support one power tool may not be able to
support two or three products.
GROUNDING INSTRUCTIONS
This product must be grounded. In the event of a
malfunction or breakdown, grounding provides a path
of least resistance for electric current to reduce the
risk of electric shock. This product is equipped with an
electric cord having an equipment-grounding conductor
and a grounding plug. The plug must be plugged into a
matching outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
Do not modify the plug provided. If it will not fi t the outlet,
have the proper outlet installed by a qualifi ed electrician.
Repair or replace a damaged or worn cord immediately.
RESIDUAL RISKS
Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual
risk factors. The following hazards may arise and the
operator should pay special attention to avoid the
following:
■ kick-back of work pieces or parts of work pieces due
to improper adjustment or handling
■ damage to the respiratory system
NOTE: Wear respiratory protection masks containing
filters appropriate to the materials being worked.
Ensure adequate workplace ventilation. Do not eat,
drink or smoke in the work area.
■ damage to hearing if effective hearing protection is
not worn.
SPECIFICATIONS
Product Specifications
Input voltage 230-240 V, 50 Hz.
Power 350 W
Motor type Induction
No load speed 11 m/sec
Blade width 6.35 mm (1/4")
Blade length 1572 mm (62")
Frame to blade capacity 230 mm (9")
Cutting thickness capacity 80 mm (3-1/8")
Table size 305 mm x 305 mm
(12" x 12")
Dust port 53 mm (2-1/8")
Work-light power 15 W, 230 V
Net weight 19.6 kg
Measured values determined according to EN61029
A-weighted sound pressure
level
L
p
= 84.0 dB(A)
Uncertainty K 3 dB(A)
Measured values determined according to EN61029
A-weighted sound power
level
L
W
= 89.5 dB(A)
Uncertainty K 3 dB(A)
Replacement parts
Band saw blade 6TPI 5132003123
Band saw blade 14TPI 5132003114
KNOW YOUR BAND SAW
See Figure 1.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual
as well as a knowledge of the project you are attempting.
Before use of this product, familiarize yourself with all
operating features and safety rules.
ANGLE ADJUSTMENT KNOB
Tilts the saw table for bevel cutting.
ENGLISH
EN
FR
DE
ES
IT
NL
PT
DA
SV
FI
NO
RU
PL
CS
HU
RO
LV
LT
ET
HR
SL
SK
BG
UK
TR
EL
13
Original Instructions
