Ryobi RT501W - Page 8

PACKAGE CONTENTS AND HARDWARE LEGEND (Continued)
8
Note: Hardware parts shown (screws, nuts, washers) are actual size.
ITEM DESCRIPTION QTY.
U Flange nut 4 U
V Footpad 4 V
WMiter pointer 1 W
X Miter bar 1 X
Y Locating pin 3 Y
Z Flat nut (M 6) 2 Z
AA Carriage bolt 1 AA
(M 6 x 30)
AB Pan head screw 16
AB
(5 x 16)
AC Countersink screw 4
AC
with nose (M 6 x 65)
