S-IDEE V913-A - Page 22

Battery
Cover
Speed
Step 1
Step 2
Throttle/direction
control lever
Fine adjustment
of direction
Trasmiitter
Push
Throttle on right hand
Forward
Backward
Turn left Turn right Left side fly Right side fly
Throttle
Mode 1
One-click
take-off/landing
Do not disassemble
Front and rear/
side fly control lever
Side flight
fine-tuning
Fine-tuning
3. NOMENCL ATURE
FORBIDDEN
Do not disassemble
FORBIDDEN
Please use 4 AA sized batteries,
installed based on polarity indicated
case. Do not mix batterles of different
chemistry/spec.
Slide the battery lid to open
by following the arrow.
- 21 -
