Saab 2005 9-3 - Page 219

217Car care
Parking lights
The parking light bulb is located in the same
reflector as the main beam bulb.
Left-hand side:
1 Lift aside the hose running along the
side of the battery cover.
2 Release the two retainers on the battery
cover and remove the cover.
3 Pull up the washer fluid filler pipe.
4 Remove the air pipe from the front edge
of the battery box.
Both sides:
1 Remove the cover from the rear of the
headlight.
2 Withdraw the bulb holder from the lamp
unit.
3 Fit the new bulb.
4 Refit the cover over the rear of the head-
light.
Left-hand side:
5 Refit the air pipe to the front edge of the
battery box.
6 Refit the washer fluid filler pipe.
7 Refit the battery cover and hose.
Front turn signal bulbs
Left-hand side:
1 Lift aside the hose running along the
side of the battery cover.
2 Release the two retainers on the battery
cover and remove the cover.
3 Pull up the washer fluid filler pipe.
4 Remove the air pipe from the front edge
of the battery box.
